Bottom Hinged Products

AW2031-168-6 in operating positionACT-2-BH in operational positionAW2031-6 with 1m offset arm COB1-1000-SF

Our bottom hinged products allow the structure to be mounted close to the perimeter wall or fence, minimising the arm length needed to locate the camera / equipment in it’s optimal position outside the perimeter. Reduced arm lengths lead to cost effective solutions and minimum foundation sizes.

Most products in this range are modular, allowing economic shipping and easier handling and access in more inaccessible locations

  • A range of products for light medium and heavy-duty applications
  • Extending arms up to 2m length depending on product type
  • Available with integral cabinet for equipment housing
  • Supported by a full range of standard accessories and supplementary steelwork
  • Constructed in high tensile steel and hot dip galvanised after fabrication for durability
  • Option of painting over the galvanised finish in colours available from BS and RAL colour charts

  • Internal cabling on most models
  • Close fitting flush doors
  • Secure locks as standard with high security lock option
  • Padlock facility on tilt-down operation to protect against un-authorised lowering

  • Data centres
  • High security facilities
  • Warehouses and industrial sites
  • Utilities sites
  • Sites requiring perimeter security

AW2031-6 in operational positionAW2031-6 in tilted service position

AW2031


AW2031 bottom hinged columns enable installations to be close to the perimeter so that cameras can either sit just inside the perimeter of project over it on offset arms. The column can then be tilted down to enable camera equipment to be serviced at ground level.

Features

  • Typically available in heights of 3-6m
  • Tilt-down facility operated from ground level
  • Sectional construction for economic transportation
  • Supplied in sections that can be man handled and assembled at ground level, for difficult access locations
  • Bolt on side arms typically up to 1m depending on camera load
  • A full range of Altron standard supporting brackets available for Fixed/PTZ/Bullet cameras, domes, lights, speakers, PIR sensors, LIDAR etc
  • Winch is demount-able and column can be padlocked, leaving it secure
  • Secure access aperture and treated back board included as standard

For further details please contact our sales department.

AW2031-168-6 in operating positionAW2031-168-6 in service position

AW2031/168


AW2031/168 bottom hinged poles enable installations to be close to the perimeter so that cameras can be positioned on the outside of the perimeter on an offset arm. The pole can then be tilted down to enable camera equipment to be serviced at ground level.

Features

  • This pole variation allows offset arm lengths of up to 2m for higher loading camera requirements.
  • Typically available in heights of 3-6m
  • Tilt-down facility operated from ground level
  • Sectional construction for economic transportation
  • Supplied in sections that can be man handled and assembled at ground level, for difficult access locations
  • A full range of Altron standard supporting brackets available for Fixed/PTZ/Bullet cameras, domes, lights, speakers, PIR sensors, LIDAR etc
  • Winch is demount-able and pole can be padlocked, leaving it secure
  • Secure access aperture and treated back board included as standard

For further details please contact our sales department

ACT-2-BH in operational positionACT-2-BH in service position

ACT/BH


Altron bottom hinged towers allow the tower to be located just inside the perimeter so that the view along the perimeter is optimised, without the use of an offset arm, for installations where a tower is the preferred option. This gives the benefit of the improved rigidity of a lattice structure. The tower can then be tilted down to enable camera equipment to be serviced at ground level.

Features

  • Typically available in heights of 3-6m
  • Provides rigid platform for higher camera equipment loads
  • Tilt-down facility operated from ground level
  • Sectional construction for economic transportation
  • Supplied in sections that can be man handled and assembled at ground level, for difficult access locations
  • A full range of Altron standard supporting brackets available for Fixed/PTZ/Bullet cameras, domes, lights, speakers, PIR sensors, LIDAR etc
  • Winch is demount-able leaving the tower secure

For further details please contact our sales department

Applicable standards


Design
- Design analysis carried out using a specialist software package in accordance with ILE TR7, BS6399 and BS8100

Material and Finishing
- Structural steel hollow sections EN10219 - EN10025:2004
- Steel flat angles and structural sections EN10025, EN10111, EN 10130
- Foundation bolts Grade 4.6 spun galvanised BS4190, BS3692, DIN931, 934, 601
- Fixings: stainless steel Grade A2, galvanised Grade 4.6  Grade 8.8  BS4190, BS3692, DIN 931, 934, 601
- Hot dipped galvanising after fabrication to ISO 1461
- Painting in BS and RAL colours in accordance with BS4800

Manufacturing Processes
- Welding Procedures conform with BS EN 1011:2009, BS EN 9606-1

Winches
- Wire ropes to BS183:1972, BS EN 13411 3 2004 + A1 2008
- Winches conform to American ASAE standard S361.IT.
